Tripp Lite
TRIPP LITE PDU3V602D354 - Tripp Lite PDU 3-Phase Vertical Strip 208V Ats 17.3KW 54 C13 Outlets 0URM
$1,173.16
$798.07
(You save $375.09)
- SKU:
- PDU3V602D354
- Condition:
- New
- Availability:
- Out of Stock
The PDU3V602D354 17.3kW 3-Phase Vertical PDU Outlet Strip is a required accessory option for Tripp Lite's PDU360AT6G60 and other 3-phase ATS PDUs that specify compatibility with this model. It's recommended for high-density equipment racks in data centers server rooms and heavily configured equipment racks.
When used with the PDU360AT6G60 the PDU3V602D354 supports up to 17.3kW total output with 27.8A balanced maximum full load per output phase combination (L1-L2 L2-L3 L3-L1) and 13.9A balanced maximum per breakered output load bank (C1-C6).
The 54 single-phase 12A 208V IEC-C13 outlets receive power from the connected ATS PDU. The outlets are interlaced to help you balance loads by spreading connections across the phase combinations throughout the rack. Each outlet is numbered and color-coded to help you keep track of connected devices and which phase combination powers each. Dual 2.5-foot power cords each with a special eight-position plug connect directly to the PDU's rear receptacles.
The PDU3V602D354's rugged all-metal housing mounts in compatible racks with no tools needed. Vertical 0U installation reduces cord clutter and improves airflow through the rack.
Features Required Accessory for Select Tripp Lite ATS PDUs
54 C13 Interlaced 208V Outlets
Installs Easily in 0U of Rack Space
When used with the PDU360AT6G60 the PDU3V602D354 supports up to 17.3kW total output with 27.8A balanced maximum full load per output phase combination (L1-L2 L2-L3 L3-L1) and 13.9A balanced maximum per breakered output load bank (C1-C6).
The 54 single-phase 12A 208V IEC-C13 outlets receive power from the connected ATS PDU. The outlets are interlaced to help you balance loads by spreading connections across the phase combinations throughout the rack. Each outlet is numbered and color-coded to help you keep track of connected devices and which phase combination powers each. Dual 2.5-foot power cords each with a special eight-position plug connect directly to the PDU's rear receptacles.
The PDU3V602D354's rugged all-metal housing mounts in compatible racks with no tools needed. Vertical 0U installation reduces cord clutter and improves airflow through the rack.
Features Required Accessory for Select Tripp Lite ATS PDUs
54 C13 Interlaced 208V Outlets
Installs Easily in 0U of Rack Space
General Information | |
Product Name | PDU 3-Phase Vertical Strip 208V Ats 17.3KW 54 C13 Outlets 0URM |
Product Model | PDU3V602D354 |
Product Type | PDU |
Technical Information | |
Output Receptacles | 54 x IEC 60320 C13 |
Power Description | |
Input Voltage | 230 V AC |
Output Voltage | 230 V AC |
Power Rating (Watt) | 17.30 kW |
Input Current | 48 A |
Physical Characteristics | |
Mounting Orientation | Vertical |
Placement | Rack |
Rack Height | 0U |
Height | 70" |
Width | 4" |
Depth | 2.2" |
Warranty | |
Limited Warranty | 2 Year |
Miscellaneous | |
Environmentally Friendly | Yes |
Environmental Certification | RoHS |
Other Information | |
Phase | Three Phase |
Stock Details | |
Manufacturer | Tripp Lite |
Manuf Part# | PDU3V602D354 |
Price | $631.61 |
Availability | In Stock |
