StarTech.com PEX16S550LP - 16-Port Low-Profile Serial Card - RS232 - PCI Express

$385.10 $261.98 (You save $123.12)
SKU:
PEX16S550LP
Condition:
New
Availability:
Out of Stock

* Prices and ETA can be changed anytime without any prior notice.
** Backorders are subject to cancellation without any prior notice.

Add 16 RS232 serial ports (DB9) to your low or full-profile computer through a PCI Express slot. This PCI Express serial card adds 16 high-speed RS232 ports to your standard or low-profile desktop or server PC. This lets you maximize the number of available DB9 RS232 ports that are available for connecting your serial-based devices and equipment while using only a single PCI Express (PCIe) slot. It's the perfect solution for adding the serial ports you need even if your desktop PC or server only has a limited number of PCIe expansion slots.

Add 16 RS232 ports through one PCIe slot

You can install the serial card to add 16 high-performance DB9 RS232 serial ports from a single PCIe slot. With two breakout cables of 8 ports each the PCIe serial card maximizes the density of DB9 RS232 ports on a server or desktop computer. It's ideal for system upgrades in a wide range of applications including manufacturing equipment POS equipment security devices such as surveillance cameras and environment or building control systems.

The serial card is compliant with PCI Express 1.0a specification and it's compatible with 1x 2x 4x 8x and 16x PCI Express slots.

High-speed serial communication

The PCIe serial card delivers high-performance high-speed serial communication with support for data transfer rates of up to 921.6 Kbps.

Easy installation

The serial card is easy to install and configure and compatible with a broad range of Windows® and Linux® operating systems. The card features IRQ sharing and supports plug-and-play serial device connections which makes it convenient and easy to connect serial devices. It includes a low-profile bracket making it compatible with both full profile and low profile PC chassis slots.

The PEX16S550LP is backed by a StarTech.com lifetime warranty and free lifetime technical support.
General Information
Product Name16-Port Low-Profile Serial Card - RS232 - PCI Express
Manufacturer Part NumberPEX16S550LP
Packaged Quantity1
Product TypeMultiport Serial Adapter
Technical Information
Host InterfacePCI Express x1
Interfaces/Ports
Ports1 x SP4 Male
Ports Expandability16 x 9-pin DB-9 Male RS-232 - Serial
Physical Characteristics
Form FactorPlug-in Card
Height0.9"
Width2.7"
Thickness6.6"
Warranty
Limited WarrantyLifetime
Miscellaneous
Environmentally FriendlyYes
Other Information
Number of Ports16
Platform SupportedLinux

PC

Stock Details
ManufacturerStarTech.com
Manuf Part#PEX16S550LP
Price$296.61
AvailabilityIn Stock
Lifetime
