Sans Digital
Sans DigitalKT-ES316X6+BHP - ES316X6+BHP 3U 16-Bay SAS with RAID PCIE Card
$4,135.55
$3,181.19
(You save $954.36)
- SKU:
- KT-ES316X6+BHP
- Condition:
- New
- Availability:
- Out of Stock
The EliteSTOR ES316X6+BHP is a 3U 16 bay 6G RAID storage rackmount for high capacity storage solutions. The ES316X6+BHP is bundled with a high-performance dual core RAID controller card that offloads complicated RAID calculations from the computer or the enclosure to the dedicated RAID engine. High performance can be achieved with a lower cost of ownership compared to RAID embedded subsystems. RAID setup and maintenance can be controlled via built-in Web Browser interfaces and the unit is supportive of e-mail notications and SNMP trap. Utilizing high bandwidth 2400MB/s mini-SAS (SFF-8088) cabling the ES316X6+BHP supports SAS or SATA hard drives to deliver superior read / write speeds that are crucial in performance-driven environments such as the video editing industry. The mini-SAS connection combines sixteen hard drive connections into a single cables reducing possible points of failures while preserving uninterrupted data transfer. A built-in SAS expansion port enables the system to connect up to 5 units or 120 HDD drives daisy-chained together. System status information such as the hard drive power supply and cooling fan status are provided by the LED. All necessary hardware comes standard including the mini-SAS cable hard drive tray modules and built-in mounting rail. The ES316X6+BHP also support SATA drives allowing users the option to choose between high performance and high capacity storage solutions.
General Information | |
Product Name | Sans Digital ES316X6+BHP 3U 16-Bay SAS with RAID PCIE Card |
Manufacturer Part Number | KT-ES316X6+BHP |
Product Line | EliteSTOR |
Product Model | ES316X6+BHP |
Product Type | DAS Storage System |
Interfaces/Ports | |
Host Interface | Mini-SAS |
Controllers | |
Controller Type | 6Gb/s SAS Serial ATA/600 |
RAID Supported | Yes |
RAID Levels | 0 1 3 5 6 10 30 50 60 JBOD 1 3 5 6 10 3+0 50 60 JBOD |
I/O Expansions | |
Number of Total Expansion Bays | 16 |
Number of 3.5" Bays | 16 |
Storage | |
Number of Hard Drives Supported | 16 |
Total Hard Drive Capacity Supported | 48 TB |
Physical Characteristics | |
Height | 5.3" |
Width | 19" |
Depth | 23" |
Form Factor | Rack-mountable |
Rack Height | 3U |
Warranty | |
Limited Warranty | 3 Year |
Miscellaneous | |
Environmentally Friendly | Yes |
Environmental Certification | RoHS |
Other Information | |
Product Family | EliteSTOR |
Number of Power Supplies Installed | 3 |
Redundant Power Supply | Yes |
Maximum Power Supply Wattage | 650 W |
Power Source | Power Supply |
Stock Details | |
Manufacturer | Sans Digital |
Manuf Part# | KT-ES316X6+BHP |
Price | $2822.70 |
Availability | Special Order |
