iStarUSA IS-500S2UP - 2U 500W RoHS Redundant Power Supply

$738.45 $568.04 (You save $170.41)

SKU:: IS-500S2UP
Condition:: New
Availability:: Out of Stock

Current Stock:

Quantity:

* Prices and ETA can be changed anytime without any prior notice.
** Backorders are subject to cancellation without any prior notice.

Description
Specification
Warranty
Reviews

IS-500S2UP ATX12V & EPS12V Power Supply offers your server and workstation zero down time with full 500W power redundancy. Active PFC temperature control fan hot swappable power modules and load sharing function provide ultimate precision power and safety protection for all electronic equipment. A good start for your mission critical system integrations.

General Information
Product Name	2U 500W RoHS Redundant Power Supply
Product Model	IS-500S2UP
Product Type	Power Supply
Technical Information
Efficiency	75%
Number of Fans	1
Power Description
Input Voltage	110 V AC 220 V AC
Output Voltage	3.3 V DC @ 32 A 5 V DC @ 32 A 12 V DC @ 40 A -5 V DC @ 500 mA -12 V DC @ 1 A 5 V DC @ 3 A
Output Power	500 W
Physical Characteristics
Form Factor	Rack-mountable
Height	3.3"
Width	4"
Depth	11.4"
Warranty
Limited Warranty	5 Year
Miscellaneous
Environmentally Friendly	Yes
Environmental Certification	RoHS
Other Information
Specification Compliance	ATX12V/EPS12V
Power Factor Correction (PFC)	Active
Hot Swappable Power Supply	Yes
Receptacles	1 x 24-pin ATX Motherboard 1 x 4+4pin EPS12V Motherboard
Input Voltage Range	100 V AC to 240 V AC
MTBF	100000 Hour
Protection Type	Over Power Over Voltage Over Current Short Circuit
Stock Details
Manufacturer	iStarUSA
Manuf Part#	IS-500S2UP
Price	$526.94
Availability	Special Order
