Antec HCG-850M - Power Supply HCG-850M 850W 80PLUS Bronze Active PFC 16PIN PCI Express 135MM

Antec HCG-850M - Power Supply HCG-850M 850W 80PLUS Bronze Active PFC 16PIN PCI Express 135MM

$174.03 $127.03 (You save $47.00)
SKU:
HCG-850M
Condition:
New
Availability:
Out of Stock

* Prices and ETA can be changed anytime without any prior notice.
** Backorders are subject to cancellation without any prior notice.

Elite power meets unrivaled performance

Antec's HCG M power supplies are the perfect combination of power and efficiency. The HCG M features special heavy-duty High Current connectors and cabling that supply extreme levels of power and superb efficiency thanks to 80 PLUS® BRONZE certification and Active PFC. HCG M's innovative 16-pin sockets create a new level of flexibility by doubling the modular connectivity supporting two different 8-pins connectors and even future connectors of 10 12 14 or 16-pins. Highest-quality connectors Japanese-brand capacitors and a quiet 135 mm LED double ball bearing fan complete the package. CircuitShield™ makes the HCG-850M safe and reliable in any environment with its nine industrial-grade protections. If loads of power High Current engineering and extreme efficiency are what you're after the HCG M is the PSU for you.
General Information
Product NameAntec Power Supply HCG-850M 850W 80PLUS Bronze Active PFC 16PIN PCI Express 135MM
Product LineHigh Current Gamer
Product ModelHCG-850M
Product TypePower Supply
Technical Information
Efficiency88%
Number of Fans1
ModularYes
ATI CrossFire SupportedYes
NVIDIA SLI SupportedYes
Power Description
Input Voltage110 V AC

220 V AC

Number of +12V Rails2
Output Voltage3.3 V DC @ 25 A

5 V DC @ 25 A

12 V DC @ 40 A

-12 V DC @ 500 mA

5 V @ 3 A

Output Power850 W
Physical Characteristics
Form FactorInternal
Height3.4"
Width5.9"
Depth6.7"
Warranty
Limited Warranty5 Year
Miscellaneous
Environmentally FriendlyYes
Other Information
Product FamilyHigh Current Gamer
Specification ComplianceATX12V/EPS12V
Power Factor Correction (PFC)Active
Input Voltage TypeAC
ColorBlack
Receptacles1 x 20+4pin ATX Motherboard

1 x 4+4pin ATX12V Motherboard

1 x 8-pin EPS12V Motherboard

4 x 6+2pin PCI-E

9 x Serial ATA

6 x 4-pin LP4 Peripheral Device

1 x 4-pin SP4 Floppy Drive

Input Voltage Range100 V AC to 240 V AC
Input Current12 A @ 110V

6 A @ 220V

Length6.7"
Protection TypeOver Current

Over Voltage

Under Voltage

Short Circuit

Over Power

Over Temperature

Surge

Inrush Current

Stock Details
ManufacturerAntec
Manuf Part#HCG-850M
Price$117.62
AvailabilityIn Stock
5 Year
