| General Information | |
| Product Name | 1600W PFC Power Supply |
| Product Line | HERCULES |
| Product Model | HERCULES-1600 |
| Product Type | Power Supply |
| Technical Information | |
| Efficiency | 85% |
| Number of Fans | 1 |
| Modular | Yes |
| ATI CrossFire Supported | Yes |
| NVIDIA SLI Supported | Yes |
| Power Description | |
| Input Voltage | 110 V AC 220 V AC |
| Number of +12V Rails | 2 |
| Output Voltage | 3.3 V DC @ 25 A 5 V DC @ 25 A 12 V DC @ 110 A 12 V DC @ 50 A -12 V DC @ 500 mA 5 V @ 3.50 A |
| Output Power | 1600 W |
| Physical Characteristics | |
| Form Factor | Internal |
| Height | 7.1" |
| Width | 5.9" |
| Depth | 3.4" |
| Warranty | |
| Limited Warranty | 5 Year |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Other Information | |
| Product Family | HERCULES |
| Specification Compliance | ATX12V/EPS12V |
| Power Factor Correction (PFC) | Active |
| Plug / Connector | Fan Control On/Off Switch |
| Input Voltage Type | AC |
| Color | Black |
| Receptacles | 1 x 20+4pin ATX Motherboard 1 x 4+4pin ATX12V Motherboard 1 x 8-pin EPS12V Motherboard 16 x 6+2pin PCI-E 6 x 4-pin LP4 Peripheral Device 16 x Serial ATA 2 x 4-pin SP4 Floppy Drive |
| Input Voltage Range | 100 V AC to 240 V AC |
| Status Indicators | LED |
| Input Current | 20 A |
| Length | 14.8" |
| MTBF | 100000 Hour |
| Protection Type | Over Voltage Overload Over Temperature Over Current Over Power Under Voltage Short Circuit |
| Stock Details | |
| Manufacturer | Rosewill |
| Manuf Part# | HERCULES-1600 |
| Price | $242.65 |
| Availability | Special Order |
